Hikvision Proactive Defence Package | CCTV + Alarm Panel 4CH 8CH 16CH
Hikvision Proactive Defence Package | CCTV + Alarm Panel 4CH 8CH 16CH
Couldn't load pickup availability
The Proactive siren & strobe cameras with two-way talk, plus a Hikvision AX HYBRID PRO alarm panel with keypad, a loud siren box and full alarm-CCTV integration. The cameras' human detection is the sensor – no PIR or door contacts – and one Hik-Connect app runs both.
主动防御 · 双向对讲、警笛及红蓝警示灯 + alarm panelAll prices are fully installed: equipment + cabling + installation & setup.
| Cameras | Equipment | Cabling | Install + alarm | Total |
|---|---|---|---|---|
|
4 cameras4 all-weather bullets 4CH DVR · 1TB HDD |
2,327 | 800 | 850 | 3,977 |
|
8 cameras8 all-weather bullets 8CH DVR · 1TB HDD |
3,126 | 1,600 | 1,050 | 5,776 |
|
16 cameras16 all-weather bullets 16CH DVR · 1TB HDD |
4,948 | 3,200 | 1,375 | 9,523 |
Install column = installation + alarm siren wiring RM200 + alarm-CCTV integration RM325. Equipment includes the AX HYBRID PRO alarm panel + keypad RM880 and the loud siren box RM80.
| Cameras | Equipment | Cabling | Install + alarm | Total |
|---|---|---|---|---|
|
4 cameras2 indoor + 2 outdoor 4CH DVR · 1TB HDD |
2,604 | 800 | 850 | 4,254 |
|
8 cameras4 indoor + 4 outdoor 8CH DVR · 2TB HDD |
3,729 | 1,600 | 1,050 | 6,379 |
|
16 cameras8 indoor + 8 outdoor 16CH DVR · 2TB HDD |
5,879 | 3,200 | 1,375 | 10,454 |
Install column = installation + alarm siren wiring RM200 + alarm-CCTV integration RM325. Equipment includes the AX HYBRID PRO alarm panel + keypad RM880 and the loud siren box RM80.
3K cameras record in 3K Lite (12 fps) on the listed DVRs.
AX HYBRID PRO alarm panel + keypad RM880 + loud siren box RM80 + siren wiring RM200 + alarm-CCTV integration setup RM325. The DVR's human detection triggers the camera siren & strobe and sets off the alarm panel's siren box; arm / disarm and alerts in the Hik-Connect app. No PIR or door contacts – the cameras do the sensing; detectors can be added to the panel's spare zones later.
Standard scope
Cameras, DVR, hard disk, 12 V power supply and DC connectors. Installation and setup include DVR & Hik-Connect app configuration, testing and handover. Each RM200 cable point covers one new camera run: 15 m RG59 coaxial cable with BNC and 15 m power cable.
DVR: 4CH iDS-7204HQHI-M1/XT · 8CH iDS-7208HQHI-M1/XT · 16CH iDS-7216HQHI-M2/XT – Hikvision AcuSense, human / vehicle detection on every channel, Hik-Connect app. 2MP cameras record at 1080p (15 fps); 5MP / 3K cameras record in 5MP Lite / 3K Lite (12 fps) on these DVRs. Installation RM325 / RM525 / RM850 for 4 / 8 / 16 cameras.
Specifications & FAQ
Hikvision equipment specifications (official hikvision.com data)
What does Proactive Defence add?
A Hikvision AX HYBRID PRO alarm panel (DS-PHA64-LP(B), 64 zones, 433 MHz) with an LCD keypad, a loud wired siren box with its own wiring, and HJ's alarm + CCTV integration setup. There are no PIR or door-contact detectors in this package – the cameras' human detection is the sensor.
How are the alarm and cameras integrated?
The AcuSense DVR's Motion Detection 2.0 classifies people on every channel. HJ configures it so a detected person triggers the camera siren & strobe and sets off the alarm panel's loud siren box, with push alerts and arm / disarm in the Hik-Connect app. Hikvision links cameras, recorders and security control panels through its device linkage (Hik-Partner Pro), and the panel also has 8 wired zones for detectors.
Is the alarm panel wired or wireless?
The panel and keypad are wired, and the panel has LAN + Wi-Fi for the app. It takes up to 64 zones – 8 wired on-board plus 56 wired or wireless (433 MHz) – so PIR detectors, door contacts, keyfobs and extra sounders can be added later.
Does the price include everything?
Yes. Cameras, DVR, hard disk, power supply, connectors, RG59 cabling, the alarm panel with keypad, the siren box and its wiring, installation, app setup and the alarm + CCTV integration are all included. The panel's 12 V 7 Ah backup battery is not included and can be added.
Can I add detectors later?
Yes. PIR detectors, door contacts, keyfobs, extra keypads and sounders can be added to the panel's spare zones – quoted separately.
Why HJ Security
- Official Hikvision authorised installer · CIDB, UPKJ, MOF certified · SICTA member
- SKM-certified technicians via UPSkillist · JKM369 Group, Google 5.0 stars
- Projects: The Podium Kuching (400+ cameras), Hilton Kuching, government facilities across Sarawak
- Products by IS Distributions; specifications from the official hikvision.com pages (checked 11 Oct 2026)
Standard installation in Kuching and across Sarawak. Prices exclude tax, junction boxes, brackets, conduit / trunking or concealed wiring, extra cable length, cabinet, UPS, access equipment, transport and extra site work – quoted after the free site survey. Payment: 100% full payment. Prices in MYR, subject to stock and site conditions.
